Nq 600m Horizontal 350m Upward Diamond Core Drill/Drilling Rig for Underground Mines

Basic Info

Model NO.	GLKD-3
Warranty	1 Year
Certification	ISO 9001:2000, ISO 9001:2008
Condition	New
Drill Hole Diameter	<100mm
Drill Hole Depth	>200m
Bit Type	Diamond Bit
Drilling Way	Rotary
Transport Package	Seaworthy Packing
Specification	2620*600*750mm
Trademark	Glorytek
Origin	Beijing, China
HS Code	8430412900
Production Capacity	20sets / Month

Product Description

GLKD-3 Full Hydraulic Underground Drilling Rig
Product Description

Technical Specifications

Spindle Rotational speed	280-1200r/min	Spindle toque	1050Nm
Axial pushing force	>65KNa	Axial pulling force	>85KNa
Hydraulic system working pressure	20MPa	Maximum pressure	25MPa
Main pump maximum pressure	31.5MPa	Auxiliary pump max. pressure	25MPa
Main pump maximum output volume	100ML/r	Auxiliary pump max. output volume	16ML/r
Power head stroke	1600mm	Surface drilling angle	0°-90°
Underground drilling angle	0°-360°	Azimuth angle	0°-360°
Motor power	75kw	Motor rotational speed	1480rpm
Machine body/size	2620*600*750mm	Weight	1335kg
Power unit	1770*1000*1420mm	Weight	1080kg
Control panel	700*400*1100mm	Weight	80kg

PicturesFeatures:
1. Small size, light weight and easy installation.
2. It consists of three major parts, the main machine, the pump station, and the operation console.
3. It can be put into production in the original transportation and exploration roadway, which plays a role in protecting the
overall structure of the mine. It can also be used for surface 0-90 degree drilling.
4. The drilling rig is arranged flexibly, and the drill pipe can be twisted and unloaded mechanized, which reduces the labor
intensity of workers and improves work efficiency.
5. The drilling rig adopts box feed frame, the gripper is tightened, the power head rotates for drilling, and the oil cylinder
pulls the drilling tool, which can save the heavy drilling tower.
6. With linkage function, centralized control through the operation console, simple and safe, and stepless speed regulation.
7. Hollow shaft design, the length of the drill pipe is not limited by the given stroke of the drill. It can drill at any
inclination angle of 360°.
8. Good disintegration, convenient relocation and transportation. φ43-φ55.5-φ71 drill pipes can be used in the same machine, and the replacement only takes 15 minutes.
9. Centralized console for oil pump, water pump and power supply.
10. The pull-out column is suitable for roadways with different heights. There are two kinds of columns: 1.8m-3m and 3m-4.5m.
11. The drill pipe is made of China advanced materials, processed with high precision and quenched to increase the service life of the drill pipe.
12. The 60 mm hole and 75 mm hole can obtain 360 degree wireline coring, the working efficiency is nearly twice that of ordinary double pipe, and the manual strength is reduced.
13. The imported oil gauge line can bear high and soft pressure, reduce the impulse of high-pressure oil pulse, make the pointer of hydraulic oil gauge more stable, and timely find the changes of stratum and rock in the hole.
14. Special customized oil temperature cooler and copper pipe in oil tank, fast cooling of high-pressure oil and low-temperature use, which can protect the service life of motor, oil pump and rubber seal.
15. The drill rig can be equipped with crawler.
16. Two people in a shift can operate skillfully in 2-5 days.

Related Products

Company Profile

Glorytek Industry (Beijing).,

located in Beijing,China, is an integrated corporation specialized in manufacturing and exporting top quality drilling equipment and drilling parts for decades. We are supported and assisted by a highly experienced team of designers and engineers that enable us to complete all the assigned projects successfully as per the specified requirement from our clients.



Our products are widely used in the scope of mining, water well drilling and exploration, anchor grouting project, side slope protection engineering, oil and gas engineering,underwater rock drilling & blasting operations of seaport channel, hydropower project, national defense projects ect.



Customer Photos



Certifications

Latest Exhibition



After-sale Warranty
Warranty of Core Drilling Rig:
(1)Within the period of the first year after delivery, the main parts of GL- IIA Trailer Mounted Drilling Rig are guaranteed to be supplied free of charge once the problem caused by the quality issue.
(2) Service at working site: If need, our technical engineer can be dispatched to the working site for technical service, but the expense of ticket, accommodation, diet, service charge shall be on buyer's account.
(3)Timely after-sale assistance shall be provided all the time.
